FP14G50SQ.26S-S
Flat Pack FP 14L
TopLine Dummy Component
For training, practice and evaluation


Click for more views

Quick Specs:
Pin Count 14L
Pitch 50 mil - 0.050" (1.27mm)
Body Size 0.255" SQ (6.5mm SQ)
Side Braze Gull-wing lead
Standard Packaging in carrier

Use and Applications:
IPC Solder Training Certification
Practice Lead Form and Trim
Equipment Evaluation
Prototype PWB

Availability:
Delivery Stock

Typical Part Number Gull Wing:
FP14G50SQ.26S-S = Solder (SnPb) Leads


Part Numbering System
FP 14 G 50 SQ .26 S - S
Series Nbr Pins Lead
Info
Pitch
Mils
Body
Shape
Body Size
Inch
Braze - Options
Flat Pack
Dual Sides
  Gull Wing

Bulk Packed
in carrier
50 Mils
0.050-inch
1.27mm
Square 0.255" SQ
6.5mm SQ
Side
Sandwich
  Solder (SnPb)
coated leads.
