DFN
Dual Flat No Lead
JEDEC MO-229

QFN Quad Side • All Daisy Chain (PDF) • M-QFN - Open Cavity • Lead Free • CTE

DFN - Dual

Leads	Pitch	Body Size	Plating Options	Ground Pad	TopLine Part Number	Daisy Chain	Solidworks Model
DFN - Dual Sided
2	-	0.6 x 0.3mm	Ni-Au (Gold)	None	DFN2-0201E7A	-	360 ° Model
6	0.65mm	2mm SQ	NiPdAu	1.6x1.0mm	DFN6E7A.65-F-DE-D	Daisy Chain	360 ° Model
6	0.65mm	2mm SQ	Sn100	1.6x1.0mm	DFN6E7A.65-T-DE-D	Daisy Chain	360 ° Model
8	0.35mm	1.6x1.9mm	Sn100	N/A	DFN8E.35-F-DE-D	Daisy Chain	360 ° Model
8	0.5mm	2mm SQ	Sn100	1.6x0.9mm	DFN8E7A.5-T-DE-D	Daisy Chain	360 ° Model
8	0.5mm	2mm SQ	NiPdAu	1.2x0.6mm	DFN8W.5-F-DE-D	Daisy Chain	360 ° Model
8	0.65mm	3mm SQ	Sn100 NiPdAu	2.3x1.5mm	DFN8M.65 DFN8T.65	Daisy Chain
10	0.5mm	3mm SQ	Sn100 NiPdAu	2.4x1.7mm	DFN10M.5 DFN10T.5	Daisy Chain

Options: Part Number Suffix: Add -TIN = Lead Free Sn100 Part Number Suffix: Add -F = Lead Free Ni-Pd-Au Part Number Suffix: Add -G = Lead Free Ni-Au (Gold) Add -DE to end of part number for Daisy Chain For Reels, Change "M or T" to "E7A"
