Standard |
||||||
| Size (inch) |
Size (metric) |
Qty on Reel |
Tape | Order Nbr 7" Reels |
Order Nbr Bulk Cassette |
PDF Dwg |
| 0201 | 0.6 x 0.3mm | 10,000 | 8mm - Paper | SR0201P7A | SR0201F | |
| 0402 | 1005 | 10,000 | 8mm - Paper | SR0402P7A | SR0402F | |
| 0603 | 1608 | 5000 | 8mm - Paper | SR0603P7A | SR0603F | |
| 0805 | 2012 | 5000 | 8mm - Paper | SR0805P7A | SR0805F | |
| 1206 | 3216 | 5000 | 8mm - Paper | SR1206P7A | SR1206F | |
| 1210 | 3225 | 5000 | 8mm - Paper | SR1210P7A | - | |
| 2010 | 5025 | 4000 | 12mm-Plastic | SR2010E7A | - | |
| 2512 | 6332 | 2000 | 12mm-Plastic | SR2512E7A | - | |
Lead Free Sn100 Tin |
||||||
| Size |
Size (metric) |
Qty on Reel |
Tape | Order Number 7" Reel |
PDF Dwg |
|
| 0402 . |
1005 | 10,000 | 8mm - Paper | SR0402P7A-TIN | ||
| 0402 Zero Ohm |
1005 | 10,000 | 8mm - Paper | SR0402P7A-ZERO-TIN | ||
| 0603 . |
1608 | 5,000 | 8mm - Paper | SR0603P7A-TIN | ||
| 0603 Zero Ohm |
1608 | 5,000 | 8mm - Paper | SR0603P7A-ZERO-TIN | ||
| 0805 . |
2012 | 5,000 | 8mm - Paper | SR0805P7A-TIN | ||
| 0805 Zero Ohm |
2012 | 5,000 | 8mm - Paper | SR0805P7A-ZERO-TIN | ||
|
Top of Page Back To Products TopLine Home |
||||||
|
Standard |
|||||
| Size (inch) |
Size (metric) |
Qty on Reel |
Tape | 7" Reel Order Number |
Order Nbr Bulk Cassette |
PDF Dwg |
| 0201 | 0.6 x 0.3mm | 15,000 | 8mm - Paper | SC0201P7A | SC0201F | |
| 0402 | 1005 | 10,000 | 8mm - Paper | SC0402P7A | SC0402F | |
| 0603 | 1608 | 4000 | 8mm - Paper | SC0603P7A | SC0603F | |
| 0805 | 2012 | 4000 | 8mm - Paper | SC0805P7A | SC0805F | |
| 0805 | 2012 | 3000 ~ 4000 | 8mm - Plastic | SC0805E7A | - | |
| 1206 | 3216 | 4000 | 8mm - Paper | SC1206P7A | SC1206F | |
| 1206 | 3216 | 3000 ~ 4000 | 8mm - Plastic | SC1206E7A | - | |
| 1210 | 3225 | 2500 ~ 4000 | 8mm - Plastic | SC1210E7A | - | |
| 1812 | 4532 | 1000 | 12mm - Plastic | SC1812E7A | - | |
| 1825 | 4563 | 1000 | 12mm - Plastic | SC1825E7A | - | |
| 2225 | 5664 | 1000 | 12mm - Plastic | SC2225E7A | - | |
Lead Free Sn100-Tin |
||||||
| Size (inch) |
Size (metric) |
Qty on Reel |
Tape | 7" Reel Order Number | PDF Dwg |
|
| 0402 | 1005 | 5000 | 8mm - Plastic | SC0402E7A-TIN | ||
| 0603 | 1608 | 4000 | 8mm - Plastic | SC0603E7A-TIN | ||
| 0805 | 2012 | 4000 | 8mm - Plastic | SC0805E7A-TIN | ||
| 1206 | 3216 | 4000 | 8mm - Plastic | SC1206E7A-TIN | ||
| 1210 | 3225 | 4000 | 8mm - Plastic | SC1210E7A-TIN | ||
| 1812 | 4532 | 1000 | 12mm - Plastic | SC1812E7A-TIN |
Top of Page Back To Products TopLine Home |
|
|
|
|||||
| Size Code |
EIA Size (metric) |
Qty on Reel |
Tape Width |
Order Number 7" Reel |
PDF Dwg |
|
| A | 3216 | 2000 | 8mm | SD3216E7A | ||
| B | 3528 | 2000 | 8mm | SD3528E7A | ||
| C | 6032 | 500 | 12mm | SD6032E7A | ||
| D | 7343 | 500 | 12mm | SD7343E7A | ||
|
Top of Page Back To Products TopLine Home |
||||||
|
|
|||||
| Size (inch) |
Size (metric) |
Body Style |
Qty on Reel |
Tape Width |
Order Number 7" Reel |
PDF Dwg |
| 0402 | 1005 | multilayer | 4000 | 8mm | SI0402P7A | |
| 0603 | 1608 | multilayer | 4000 | 8mm | SI0603P7A | |
| 0805 | 2012 | multilayer | 3000~4000 | 8mm | SI0805E7A | |
| 1008 | 2520 | molded | 2000 | 8mm | SI1008E7A | |
| 1206 | 3216 | multilayer | 2000 | 8mm | SI1206E7A | |
| 1210 | 3225 | molded | 2000 | 8mm | SI1210E7A | |
| 1812 | 4532 | molded | 1000 | 12mm | SI1812E7A | |
|
Top of Page Back To Products TopLine Home |
||||||
|
Standard |
|||||
| Size (inch) |
Name | Qty on Reel |
Tape Width |
Order Number 7" Reel |
PDF Dwg |
|
| 0604 | micro-MELF | 3000 | 8mm | SRM0604E7A | ||
| 0805 | micro-MELF | 3000 | 8mm | SRM0805E7A | ||
| 1206 | mini-MELF | 3000 | 8mm | SRM1206E7P | ||
| 1406 | mini-MELF | 3000 | 8mm | SRM1406E7P | ||
| 2308 | MELF | 1500 | 12mm | SRM2308E7A | ||
Lead Free Sn100 Tin |
||||||
| Size (inch) |
Name | Qty on Reel |
Tape Width |
Order Number 7" Reel |
PDF Dwg |
|
| 0805 . |
micro-MELF | 3000 | 8mm | SRM0805E7A-TIN | ||
| 0805 Zero Ohm |
micro-MELF | 3000 | 8mm | SRM0805E7A-ZERO-TIN | ||
| 1206 . |
mini-MELF | 3000 | 8mm | SRM1206E7P-TIN | ||
| 1206 Zero Ohm |
mini-MELF | 3000 | 8mm | SRM1206E7P-ZERO-TIN | ||
| 2308 . |
MELF | 2000 | 12mm | SRM2308E7A-TIN | ||
| 2308 Zero Ohm |
MELF | 2000 | 12mm | SRM2308E7A-ZERO-TIN | ||
|
Top of Page Back To Products TopLine Home |
||||||
|
PDF Data Sheet |
|||||
| Size Diameter x Height |
Qty on Reel | Tape Width | Tape Pitch | Order Number | ||
| 3mm x 5.5mm | 2000 | 12mm | 8mm | SE3E13A | ||
| 4mm x 5.5mm | 2000 | 12mm | 8mm | SE4E13A | ||
| 5mm x 5.5mm | 1000 | 12mm | 12mm | SE5E13A | ||
| 6.3mm x 5.5mm | 1000 | 16mm | 12mm | SE6E13A | ||
| 8mm x 6.2mm | 1000 | 16mm | 12mm | SE8E13A | ||
| 8mm x 10mm | 500 | 24mm | 16mm | SE9E13A | ||
| 10mm x 10mm | 500 | 24mm | 16mm | SE10E13A | ||
| 12.5 x 13.5mm | 200~250 | 32mm | 24mm | SE12E13A | ||
| 12.5mm x 16mm | 150~200 | 32mm | 24mm | SE13E13A | ||
| 12.5mm x 21mm | 125 | 32mm | 24mm | SE14E13A | ||
| 16mm x 16.5mm | 125~150 | 44mm | 28mm | SE16E13A | ||
| 16mm x 21.5mm | 75~100 | 44mm | 28mm | SE17E13A | ||
| 18mm x 21.5mm | 75 | 44mm | 32mm | SE18E13A | ||
| 18mm x 16.5mm | 75 ~ 125 | 44mm | 32mm | SE19E13A | ||
| 20mm x 16.5mm | 50 | 44mm | 36mm | SE20E13A | ||
|
